Audio and video in

Video in

8 HDMI

Audio in

8 HDMI Built in audio

Video Encode

Encoding type

H.265

FPS

5-60

GOP

5-300

Bitrate(kbit)

32-32000

Encoded size:

1920x1080/1680x1056/1280x720/1024x576/850x480/720x576/720x540/720x480/720x404/
704x576/640x480/640x360/608x448/544x480/480x480/480x384/480x360/480x320/480x272
/480x270/400x320/400x224/352x480/352x228/320x256/320x240/320x180/240x180/176x144/
ssame as the input

Bitrate control

CBR/VBR

stream

TS/HLS/RTSP/FLV/RTMP/SRT/UDP/RTP Multicast

Audio Encode

Samplerate

44100/48000

Encoder

AAC/AAC+/AAC++/MP3/MP2/AC3

Bitrate：

AAC:48000-256000  /AAC+:24000-48000 /

AAC++:12000-32000 /MP3:64000-320000 /

MP2: 64000-320000 / AC3:40000-640000

G711A Over RTSP

Disable/Enable

Digital volume

-50--50

OSD

Alpha

0-128

Text

Disable/Enable

Font size

8-72

X coordinate

0-1920

Y coordinate

0-1080

Background color

transparent /White/ black

Font color

RGB Can choose

LOGO

upload 16 LOGO

Common

Network

Set IP，gigabit Lan RJ45

configuration

WEB，Upload，Reset

Power Supply

12V/DC,2A

Power

<5W

Temperature

-20℃+60℃

humidity

<90%, non-condensing

Size

23.5*11.2*3cm

weight

  796g
