H.264 SDI Video Encoder with Loop out

H.264 SDI Video Encoder with Loop out

Model: ESL310



Products Description

HD SDI Encoder is a professional audio and video encoding products, which support the product supports 1 channel HD-SDI

audio and video collection capabilities and an SDI loop out, encoded output dual stream H.265 or H.264 format and audio MP3,

AAC format . It is able to freely adjusted according to need. The device is highly integrated, cost-effective. Support HTTP / RTSP

/ RTP / RTMP / UDP transport protocols. Support external audio input.


Feature:

* Support HD resolution 1920x1080p/1920x1080i/1280x720p/720*576i/640*480i (can be customized)

* Supports SDI input, SDI output

* Supports WINDOWS and LINUX

* Support multiple devices display on a computer at the same time

* Support RTSP/RTP/RTMP/HTTP/UDP unicast and multicast protocol (RTMP support adding users and changing passwords),

* Support the SDI input and up to 1080p, 720P HD SDI input

* Support Main TS stream and the sub TS stream  use in different network protocols for transmission (Multi-rate multi-protocol

support)H. 264,H.265

* Encoding level: 1, 2, 3, 4 and 5 (the higher the level ,the larger of the code flow fluctuation ratio )

* Coding Standards BASELINE PROFILE / MAIN PROFILE / HIGH PROFILE, H.265:audio MP3, AAC, sampling rate: 32000,44100,

48000 etc., Encoded audio bit rate: 48K, 64K, 96K, 128K, 160K, 192K, 256K

* Rate Control CBR / VBR 16KBIT / S ~ 12MBIT / S

* Video packaging: A mode: FFMPEG, B mode: VLC

* Transmission: TCP, UDP, 1000M (RJ45 Ethernet port duplex)

* Support WEB access in Chinese/English, passwords changing, WAN remote management (WEB)

* Support OSD in Chinese/ English, support OSD rolling, images superimposing, support adding LOGO ,Characters and symbols;

Adjustable coordinates: 1920x1080; The font size resolution: 8 to 72.

* Support DHCP gaining IP automatic ,support One-key recovery, upgrade and remote maintenance

* Image settings: contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering

* Support build-in or external methods , support left and right sound channel , Support audio gain ,be able to turn volume individually

* Support no video signal coding;

* Complete the setting effect immediately, don’t need to restart

* Support one-key recovery of the default configuration

* Support set-top box decoder

* The low power consumption design
