HDMI Repeater 8K60Hz

HDMI Repeater 8K60Hz

Model: HRE03



Products Description

Introduction :

 This HDMI repeater can realize signal enhancement by signal equaliztion and

reorganization, so that the signal can be transmitted to longer distance. The Resolution of

this HDMI repeater can be up to:7680x4320/60Hz.


Features :

* Support CEC;

 Support 3D video format;

* Support repeater up to 7680x4320/60Hz;

* Product shape is small and beautiful.

Specifications:

HDMI resolution …………………….…....….….....................…...................... up to 8K/60Hz

Support audio format …………….................. DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD

Support video format ……………........................…………..………… 8/10/12bit Deep color

Max baud rate ……………….…….……………...…………………...................….. 4x12Gbps

Input cable distance ..…...…........................................ ≤15M AWG24 HDMI standard cable

Output cable distance ….............................................. ≤10M AWG24 HDMI standard cable

Operating Temperature range ……...........….…...……..………………………. (-15 to +45℃)

Operating Humidity range ……....….....……...……..….….. 5 to 90%RH (No Condensation)

Dimension (L x W x H) ...……………...……….……....……………....…...…. 52x25x14 (mm)

Weight …..………………………..………………..…....……….…...........….….......….…... 15g
