HDMI Splitter 1x2 4K

HDMI Splitter 1x2 4K

Model: HSP102



Products Description

Introduction:

The 1x2 HDMI Splitters uses a single HDMI source,accessing to multiple HDMI sinks.It

allows one HDMI device to be split easily to 2 HDMI compatible monitors or projectors.In

addition,it can be placed at the end of a long HDMI cable to regenerate the HDMI signal.

The resolution of this hdmi splitter can be up to 3840x2160/30Hz.


Features:

* Support HDMI 1.4b

* Support Full 3D

* Support HDMI resolution up to 3840x2160/30Hz

* Support the max baud rate of 3.4G and max bandwidth of 340Mhz

* Support deep color 8/10/12bit

* Support input up to 8 metres AWG26 HDMI standard cable length, output up to 8 metres

 AWG26 HDMI standard cable length

* Displaying single source, multi-output high-definition signal source from DVD player A/V

 receiver, set-top box

* 5V/1A power adapter


Specifications:

HDMI version ……………………………………………..…………………………. HDMI 1.4b

HDMI resolution ………………………………..………….……….……up to 3840x2160/30Hz

Support video format ……………………………………...……..………8/10/12bit Deep color

Support audio format…………………....…….DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD

Max bandwidth………………………...………………………………………………….340MHz

Max baud rate……………….…….…………....………………….……………………..3.4Gbps

Input cable distance.…………………………...………….≤8m AWG26 HDMI standard cable

Output cable distance………………………..……………≤8m AWG26 HDMI standard cable

HDMI input……………………………………....…………………………………………1 HDMI

HDMI output…………………………………..……………………………………………2 HDMI

Max working current……………………………………..………………………………....500mA

Specifications of power adapter…….input AC (50Hz, 60Hz) 100V-240V; output: DC5V/1A

Operating Temperature range………………………………….….……………(-15℃to +55℃)

Operating Humidity range…………………………...……….5 to 90%RH (No Condensation)

Dimension (L x W x H)……………….............………….....……………….128x53x23.5 (mm)

Weight…….…..…………………………………..………………..…….……………………139g
