HDMI 2.0 Splitter 1x2 4K60Hz

HDMI 2.0 Splitter 1x2 4K60Hz

Model: HSP102-P



Products Description

Product introduction:

The 1x2 HDMI Splitter uses a single HDMI source,accessing to multiple HDMI sinks.It

allows one HDMI device to be split easily to 2 HDMI compatible monitors or projectors.In

addition,it can be placed at the end of a long HDMI cable to regenerate the HDMI signal.

The resolution of this hdmi splitter can be up to 3840x2160/60Hz.


Features:

* Support HDCP2.2 ;

* Support HDR ;

* Support Full 3D ;

* Support 4K to 2K output ;

* Support HDMI resolution up to 3840x2160/60Hz ;

* Support the max baud rate of 6G and max bandwidth of 600Mhz ;

* Support deep color 8/10/12bit ;

* upport input up to 15 metres AWG26 HDMI standard cable length,

 output up to 20 metres AWG26 HDMI standard cable length(1080p,4k/30Hz resolution) ;

* Support input up to 5meters AWG26 HDMI Standard cable length,output up to 5m (4K/60Hz resolution) ;


Specifications:

HDMI resolution ………………………………..………….……….……up to 3840x2160/60Hz

Support video format ……………………………………...……..………8/10/12bit Deep color

Support audio format…………………....…….DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD

Max bandwidth………………………...…………………………………………...……. 600MHz

Max baud rate……………….…….…………....………………….……………………...18Gbps

Input cable distance.…..….…………....………………….1080P,4K 30Hz≤15m,4K 60Hz≤5m

AWG26 HDMI standard cable

Output cable distance…….…………....………………….1080P,4K 30Hz≤20m,4K 60Hz≤5m

AWG26 HDMI standard cable

HDMI input……………………………………....…………………………………………1 HDMI

HDMI output…………………………………..……………………………………………2 HDMI

Max working current……………………………………..………………………………....450mA

Operating Temperature range………………………………….….……………(-15℃to +55℃)

Operating Humidity range ..…………………………...…… 5 to 90%RH (No Condensation)

Dimension (L x W x H) ……………….............………….....………………. 123x56x15 (mm)

Weight …….…..…………………………………..………………..…….……………...… 64.5g
