Introduction:

 The 1x10 HDMI Splitter uses a single HDMI source,accessing to multiple HDMI sinks.

It allows one HDMI device to be split easily to 10 HDMI compatible monitors or

projectors. In addition，it can be placed at the end of a long HDMI cable to regenerate

the HDMI signal. The resolution of this hdmi splitter can be up to 8K/60Hz.

 This splitter supports EDID management function, comes with eight kinds of EDID mode,

the users can choose according to their own needs. In addition, this product is also built-in

IR extension function, it can work with our hdmi 2.0V repeater which has IR-RX to receive

the IR command to control the source.

Features:

* Support HDR;

* Support 3D video format;

* Support CEC（only output1);

* Support high resolution up to 8K/60Hz;

* Remote control the source （via the IR-RX of HDMI repeater which splitter works

 with to receive the IR command);

* Support EDID management;

* Support output downscaling.

Specifications:

HDMI resolution ………………………………...………..……....................... up to 8K/60Hz

Support video format ……………………….................………..….... 8/10/12bit Deep color

Support audio format …………….............. DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD

Max baud rate …………….…….………………........................….………………... 40Gbps

Input cable distance ………………….......... (8K resolution)≤5m HDMI2.1 standard cable

Output cable distance ………………........... (8K resolution)≤5m HDMI2.1 standard cable

Max working current ……………....................……………………………………...…... 1.2A

Power adapter format …….......... input AC (50Hz, 60Hz) 100V-240V; output: DC12V/2A

Operating temperature range …...........……………………….…………… (-15℃to +55℃)

Dimension (L x W x H) ……………...............…...................……….…… 375x89x22 (mm)

Weight ….…..…………………………………..……...........................……………....... 780g
