HDMI 2.0 Switch Splitter 2x4 4K60Hz

HDMI 2.0 Switch Splitter 2x4 4K60Hz

Model: HSS204-V2.0



Products Description

The 2 x 4 HDMI switch splitter can connect 2 hd signal sources to 4 hd display terminals.

It can easily split the 2 hd signals generated by the 2 hd signal sources to 4 hd displayers or

projectors.In addition, when connect it to a HDMI output cable, it can amplify the HDMI singal.

The 2 signal sources can be switched freely.The HDMI splitter can support all hd multichannel

audio formats including 720p, 1080i, 1080p,2160p@30Hz,2160p@60Hz. It also supports the

3.5 mm audio output and SPDIF audio output.


Features:

1.Downscaling (can output 4K and 1080p at the same time)

2.High Definition,it can support 4K/60Hz RGB/YUV 4:4:4

3.Transmission long distance,4K/60Hz up to 10meters,1080p up to 20meters


Specifications:

HDMI resolution …………………....…....…….......................…….……..up to 3840*2160/60Hz

Support video color format ………………................…..………………….8/10/12 bit deep color

Support audio format…...…….....................…….DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD

Max bandwidth…………………………........…....………………………………………… 600MHz

Max baud rate……………….……………………..........………………………...………….. 6Gbps

Input cable distance……................................….(1080p resolution) ≤20m,(4K resolution)≤10m

AWG26 HDMI standard cable

Output cable distance………………...….…...…(1080p resolution) ≤20m, (4K resolution)≤10m

AWG26 HDMI standard cable

Max working current……………………...………………………..........……......………..... 500mA

Power adapter format...........................Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A

Operating Temperature range……..…............……………………...…………… (-15℃to +55℃)

Dimension (L x W x H).......................………………….………...………………200x70x25 (mm)

Weight…..………...……………………….........………………..…...….………………………280g
