4K 60Hz HDMI Switch 4x1 with Audio Extractor

4K 60Hz HDMI Switch 4x1 with Audio Extractor

Model: HSW401-N2.0



Products Description

Introduction:

The 4x1 hdmi switch support four HDMI ports by remote control or button to switch to

 a display terminal. The HDMI switch can support all hd formats including720p, 1080i,

1080p, 2160p multichannel audio.This product comes with digital audio outputs (optical

fiber and coaxial) and one 3.5 mm headphone output , so it is more suitable for

home theater systems.


Features:

* Support 3D

* Support HDCP 2.2

* Support highest video resolution 3840x2160/60Hz

* Support ARC

* Support 24/30/36 bit deep color

* Support single and high definition display for multiple sources, such as DVD

 Players, A/V Receivers and Set top boxes

* DC5V/1A power supply


Specifications:

HDMI resolution …………………………………………….....Up to 3840x2160/60Hz

Support video format............................................................................................3D

Support video color format ………………………..........…....24/30/36 bit deep color

Support audio format.........................DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD

Max bandwidth…………………………………………………….……………..600MHz

Max baud rate……………….…….………………….……....……………......6X3Gbps

Input cable distance..….........≤5m(4K 60Hz),≤ 15m(4K 30Hz)1080p AWG26 HDMI

standard cable

Output cable distance………≤5m(4K 60Hz),≤ 15m(4K 30Hz)1080p AWG26 HDMI

standard cable

Max working current………………………………….………………………......450mA

Power adapter format Input...........AC (50Hz, 60Hz) 100V-240V; Output: DC5V/1A

Operating Temperature range……..………...….…………………….(-15℃ to +55℃)

Dimension (L x W x H)………………………………….….………….167x67x28 (mm)

Weight…..……………………………………………..…….………………………..240g
